Corvalent Q35SBC overview
Corvalent Q35SBC Motherboard Intel® Core™ 2 Quad Q9400, Intel Core 2 Duo E8400, E6400, E4300, E2160 Intel Q35 Express chipset Two (2) SATA 2.0 ports Twelve (...
Product details
Manufactured byCorvalent
Product groupMotherboard
DescriptionCorvalent Q35SBC Motherboard
Product HighlightsIntel® Core™ 2 Quad Q9400, Intel Core 2 Duo E8400, E6400, E4300, E2160 Intel Q35 Express chipset Two (2) SATA 2.0 ports Twelve (12) USB 2.0 ports Up to 4GB of DDR2 PICMG 1.0 Compliant One (1) PATA 100 port, supports one (1) IDE device Seven (7) to Ten (10) Year Guaranteed Production
Typical ApplicationsSecurity & Surveillance Telecommunications Defense Medical Networking Factory Automation Robotics
OverviewThe Q35SBC single board computer (SBC) is a full-size PICMG 1.0 compliant CPU card (13.3” x 4.8”) based on the Intel® Core™ 2 Duo and Intel Celeron® processor. The Q35SBC was designed specifically for performance intensive embedded applications such as Security & Surveillance, Telecommunications, Defense, Medical, Networking, Factory Automation, and Robotics.The Intel Core 2 Duo processor enables the Q35SBC to be cooled by a low-profile heat sink and fan. This signifi cantly reduces the amount of horizontal space the SBC takes up in the backplane and allows usage of expansion card slots that would normally be blocked by a larger standard processor fan.The Intel Q35 Express chipset addresses key requirements of many embedded computing designs, including graphics, low-power consumption, noise reduction, manageability, data protection and security. When combined with Intel Core™ 2 Duo processors, the Q35SBC platform helps embedded OEM’s deploy responsive, high-performance, lowpower systems
