Monolithic Power Systems EV3414-J-00A overview
Monolithic Power Systems EV3414-J-00A Synchronous Boost Converter Evaluation Board The EV3414-J-00A is a Boost converter evaluation board for the MP3414, a sync...
Manufactured byMonolithic Power Systems
Part number or familyEV3414-J-00A
Product groupSynchronous Boost Converter Evaluation Board
Product details
Manufactured byMonolithic Power Systems
Product groupSynchronous Boost Converter Evaluation Board
DescriptionMonolithic Power Systems EV3414-J-00A Synchronous Boost Converter Evaluation Board
OverniewThe EV3414-J-00A is a Boost converter evaluation board for the MP3414, a synchronous, 1 MHz fixed-frequency, current-mode step-up converter with output-to-input disconnect. The device can step up single-cell and two-cell alkaline, NiCd, and NiMH batteries up to 4V.It can start up from an input voltage as low as 0.8V and provides inrush current limiting as well as output short-circuit protection.The output voltage can also be regulated when VIN>VOUT, and the P-channel MOS is no longer acting as a low-impedance switch.The EV3414-J-00A regulates the output voltage up to 3.3V from a single AA cell without an external Schottky diode.The MP3414 is offered in a TSOT23-8 package.
Key FeaturesUp to 96% Efficiency True Output Load Disconnect Input Range: 0.6V to 4V Output Range: 1.8V to 4V 0.8V Low Voltage Start-Up Current Mode Control with Internal Compensation Short-Circuit Protection True Output Disconnect from Input VIN>VOUT Down Mode Operation High Efficiency at Light Load Conditions Inrush Current Limit and Internal Soft-Start 1MHz Fixed Frequency Switching Tiny External Components
Typical ApplicationsSingle-Cell and Two-Cell Alkaline, NiCd, or NiMH Batteries Powered Products Personal Medical Devices Portable Media Players Wireless Peripherals Handheld Computers and Smart phones
